Riders seeking a one-of-a-kind touring experience
Bold styling with Kahuna™ controls and a fang front spoiler
Built for urban riding, equipped for exploration.
- Engine
- Dimensions
- Performance
- Drivetrain
- Chassis
- Electric
Engine
Bore
Stroke
Displacement
Compression Ratio
Fuel System
Exhaust
Liquid-cooled, Parallel-Twin, 500cc
69 mm
66.8 mm
500 cc
11.5:1
Electronic Sequential Port Fuel Injection (ESPFI)
2 into 1 short single, 3 catalyst
Length
Ground Clearance
Rake
Trail
Wheelbase
Tyres, Front Specification
Tyres, Rear Specification
Tyre, Type
Fuel Capacity
Oil Capacity (w/filter)
Weight, As Shipped
Weight, In Running Order
2,135 mm
153 mm
24.5
100.4 mm
1,485 mm
120/70-ZR17/58W
160/60-ZR17/69W
Maxxis Supermaxx ST
13.1 l
3.2 l
199 kg
208 kg
Engine Torque Testing Method
Engine Torque
Engine Torque (rpm)
Horsepower
Lean Angle, Right (deg.)
Lean Angle, Left (deg.)
Fuel Economy Testing Method
Fuel Economy
GB/T20076-2006, GB/T5363-2008
46 Nm
6,000
47 HP / 35 kW @ 8500 rpm
46.9
49.5
WMTC
4.85 l/100 km
Primary Drive
Gear Ratios (overall) 1st
Gear Ratios (overall) 2nd
Gear Ratios (overall) 3rd
Gear Ratios (overall) 4th
Gear Ratios (overall) 5th
Gear Ratios (overall) 6th
Chain, 74/38
2.85
1.95
1.56
1.33
1.19
1.08
Front Fork
Rear Shocks
Wheels, Front Type
Wheels, Rear Type
Brakes, Caliper Type
50mm upside down rebound adjustable
Oil and gas separation type, rebound damping adjustable, preload adjustable shock absorber
Cast aluminium
Cast aluminium
4-piston fixed front and 1-piston floating rear
Lights (as per country regulation), Indicator Lamps
Gauges
All LED, low beam, high beam and signature position lamp. All LED Tail/Stop, front signal lights and rear turn signals.
Combined electronic instrument stepper motor indicating vehicle speed, digital indicates rpm, hour, total trip, two trips (A + B), km/mile indication
Adjustable front and rear suspension gives you full control to match comfort with performance.
