THIS IS THE RIGHT BIKE FOR
Riders who desire top-of-the-line performance and stunning style
Aggressive riding with sport bike agility and handling
Making a statement and standing out from the crowd
All-new Revolution Max 1250T
The next chapter in a century of legendary V-Twins is here. Revolution Max is a liquid-cooled powertrain with double overhead camshafts and variable valve timing: offering ample torque and an immediate powerband tuned to maximise rider control.
- Engine
- Dimensions
- Performance
- Drivetrain
- Chassis
- Electric
Engine
Bore
Stroke
Displacement
Compression Ratio
Fuel System
Exhaust
Revolution® Max 1250T
105 mm
72.3 mm
1,252 cc
12.0:1
Electronic Sequential Port Fuel Injection (ESPFI)
2-into-1-into-2; catalyst in muffler
Length
Ground Clearance
Rake
Trail
Wheelbase
Tyres, Front Specification
Tyres, Rear Specification
Tyre, Type
Fuel Capacity
Oil Capacity (w/filter)
Weight, As Shipped
Weight, In Running Order
2,270 mm
90 mm
30
148 mm
1,520 mm
160/70R17 73V
180/70R16 77V
Dunlop® Harley-Davidson Series, radial
11.8 l
4.5 l
221 kg
228 kg
Engine Torque Testing Method
Engine Torque
Engine Torque (rpm)
Horsepower
Lean Angle, Right (deg.)
Lean Angle, Left (deg.)
Fuel Economy Testing Method
Fuel Economy
J1349
127 Nm
6,000
90 kW
34
34
EU 134/2014
5.1 l/100 km
Primary Drive
Gear Ratios (overall) 1st
Gear Ratios (overall) 2nd
Gear Ratios (overall) 3rd
Gear Ratios (overall) 4th
Gear Ratios (overall) 5th
Gear Ratios (overall) 6th
Gear, 49/89 ratio
12.21
9.022
6.994
5.641
4.731
4.131
Front Fork
Rear Shocks
Wheels, Front Type
Wheels, Rear Type
Brakes, Caliper Type
43 mm inverted fork with compression, rebound and spring preload adjustability. Aluminium fork triple clamps.
Linkage-mounted, piggyback monoshock with compression, rebound and hydraulic spring preload adjustability
Aluminium cast, satin black
Aluminium cast, satin black
Front: radially mounted, monoblock, 4-piston caliper; Rear: floating, single piston caliper
Lights (as per country regulation), Indicator Lamps
Gauges
All LED headlamp, low and high beam with signature position lighting. All LED Tail/Stop lamp with signature tail lighting, LED Bullet Turn Signals front and rear
4 inch viewable area TFT display with speedometer, gear, odometer, fuel level, clock, trip, ambient temp, low temp alert, side stand down alert, TIP over alert, cruise, range and tachometer indication BT capable - phone pairing to access phone calls, music, navigation (H-D App ONLY)
