THIS IS THE RIGHT BIKE FOR
Riders seeking a one-of-a-kind 3-wheel touring experience
Bold styling with premium paint and Tomahawk™ wheels
Twin-Cooled™ Milwaukee-Eight™ 114 engine and premium tech
TWIN-COOLED™ MILWAUKEE-EIGHT™ 114 ENGINE
The most displacement in standard H-D™ Touring models. You get 114 cubic inches of passing and horizon-chasing power.
- Engine
- Dimensions
- Performance
- Drivetrain
- Chassis
- Electric
Engine
Bore
Stroke
Displacement
Compression Ratio
Fuel System
Exhaust
Twin-Cooled™ Milwaukee-Eight™ 114
102 mm
114.3 mm
1,868 cc
10.5:1
Electronic Sequential Port Fuel Injection (ESPFI)
2-1-2 dual exhaust with tapered mufflers
Length
Ground Clearance
Rake
Trail
Wheelbase
Tyres, Front Specification
Tyres, Rear Specification
Tyre, Type
Fuel Capacity
Oil Capacity (w/filter)
Weight, As Shipped
Weight, In Running Order
Luggage Capacity-Volume
2,670 mm
125 mm
26
100 mm
1,670 mm
MT90B16 72H
P205/65R15 92T
Dunlop™ Harley-Davidson Series, bias blackwall front and radial blackwall rear
22.7 l
4.7 l
546 kg
564 kg
0.19 m3
Engine Torque Testing Method
Engine Torque
Engine Torque (rpm)
EC134/2014
159 Nm
3,000
Primary Drive
Gear Ratios (overall) 1st
Gear Ratios (overall) 2nd
Gear Ratios (overall) 3rd
Gear Ratios (overall) 4th
Gear Ratios (overall) 5th
Gear Ratios (overall) 6th
Chain, 34/46 ratio
10.534
7.302
5.423
4.392
3.741
3.157
Front Fork
Rear Shocks
Wheels, Front Type
Wheels, Rear Type
Brakes, Caliper Type
49mm dual bending valve
Hand-adjustable emulsion rear suspension
Black, 7-spoke Cast Aluminium
Black, 7-spoke Cast Aluminium
Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
Lights (as per country regulation), Indicator Lamps
Gauges
All LED, low beam, high beam and signature position lamp headlamp; Incandescent Tail/Stop, Front Signal Lights and Rear Turn Signals
Speedometer, tachometer, fuel, and voltage gauges; display features odometer, trip A, trip B, range to empty, gear indicator
